Commercial dishwashers
ULTRA
The Premium washing experience, by Sammic
5 models
UX-50 LITE
Rack size 500 mm x 500 mm and door clearance 380 mm.
UX-50
Rack size 500 mm x 500 mm and door clearance 380 mm. Multi-power version.
UX-50C
Rack size 500 mm x 500 mm and door clearance 380 mm. Constant temperature rinsing system.
UX-50 ISO
Rack size 500 mm x 500 mm and door clearance 380 mm. Double-skinned construction.
UX-50 ISO C
Rack size 500x500mm and door clearance 380 mm. Double-skinned construction.
Soft start:
- Progressive start-up of the washing pump to protect fragile items.
Colour LCD display
- Intuitive communication of the machine status by means of messages, colour codes and icons.
- Control panel with IP65 humidity protection.
Dedicated cycles
- Selection of the ideal washing programme using icons.
Maximum efficiency
- Energy-saving function: temperature-reduction and electricity consumption saving during periods of temporary inactivity of the machine (25').
- Machine shutdown due to total inactivity (2 h).
Adaptability and control
- Adaptable: allows the main parameters of the machine to be adjusted to the needs of each user.
- Dosage control from control board by authorised personnel.
- Temperature display.
- "Wash plus+" function: increases the intensity of the wash cycle for greater cleaning performance
- Your machine, tailor-made for you: list of options.
B or PROACTIVE PLUS models include extra features:
- Proactive washing water renewal: 15% of the washing water is renewed after each washing cycle, keeping the washing capacity constant throughout the day.
- Self-cleaning cycle: the machine performs a self-cleaning cycle at the end of the shift, facilitating maintenance tasks and ensuring the cleaning of the tank.
Maximum protection for your glassware
Soft start: progressive start-up of the washing pump to protect fragile or delicate items.
Colour LCD display
Automatic cycle start included.
Comparison ULTRA
| ULTRA | |||||
|---|---|---|---|---|---|
 | | |  | | |
| UX-50 LITE | UX-50 | UX-50C | UX-50 ISO | UX-50 ISO C | |
| Features | |||||
| Basket dimensions | 500 x 500 mm | 500 x 500 mm | 500 x 500 mm | 500 x 500 mm | 500 x 500 mm |
| Useful height | 380 mm | 380 mm | 380 mm | 380 mm | 380 mm |
| Electronic control panel | yes | yes | yes | yes | yes |
| Wash temperature display | yes | yes | yes | yes | yes |
| Rinse temperature display | yes | yes | yes | yes | yes |
| Constant temperature rinsing | - | opt. | yes | opt. | yes |
| Rinse pressure pump | - | opt. | yes | opt. | yes |
| Wash tank capacity | 14 l | 14 l | 14 l | 14 l | 14 l |
| Double skin | - | opt. | opt. | yes | yes |
| Cycles | |||||
| Cycles | 6 | 6 | 6 | 6 | 6 |
| Cycle duration | 90 / 110 / 120 / 180 / 240" | 90 / 110 / 120 / 180 / 240" | 90/110/120 / 180 / 240" | 90 / 110 / 120 / 180 / 240" | 90 / 110 / 120 / 180 / 240" |
| Production baskets / hour | 40 / 33 / 30 / 20 / 15 | 40 / 33 / 30 / 20 / 15 | 40 / 33 / 30 / 20 | 40 / 33 / 30 / 20 / 15 | 40 / 33 / 30 / 20 / 15 |
| Loading | |||||
| Pump power | 1 Hp / 750 W | 1 Hp / 750 W | 1 Hp / 750 W | 1 Hp / 750 W | 1 Hp / 750 W |
| Tank | 1800 W | 1800 W | 1800 W | 1800 W | 1800 W |
| Boiler | 3000 W | 5000 W | 5000 W | 5000 W | 5000 W |
| Total loading | 3750 W | 5750 W | 5750 W | 5750 W | 5700 W |
| External dimensions (W x D x H) | |||||
| External dimensions (W x D x H) | 580 x 635 x 835 mm | 580 x 635 x 835 mm | 580 x 635 x 835 mm | 600 x 640 x 835 mm | |
| Please note: the width of double skinned models increases by 20 mm. | |||||
| Data with water entry at 55ºC (recommended) | |||||
Commercial dishwashers
Undercounter front loading commercial dishwashers
Washing efficiency, reliability, hygiene, ergonomics, optimised consumption, ... these are the technical attributes that every professional needs. That's why Sammic is offering two ranges of dishwashers based on a common core.
Sani-Control guarantee
- GUARANTEED DISINFECTION in compliance with standard DIN 10534.
- "THERMAL LOCK" function: ensures that rinsing will be carried out at the ideal temperature to disinfect the dishes.
Deep drawn tanks
- Ergonomic design with rounded corners to prevent the accumulation of dirt and facilitate cleaning.
- Compact tank volume (50% water saving compared to the previous range).
- Embedded basket guides.
Hydroblade™ washing arms
- Redesigned nozzles for greater washing performance.
- The "monoblock" design delivers durability and resistance to impacts.
- 30% savings in water consumption during rinsing compared to the previous range.
3-stage filter system: surface, tank and extraction
- Keeps the washing water in optimal conditions to maintain constant washing performance.
"Easy-grip" door: new design with integrated door handle
- Designed to have no corners or areas that are difficult to access: prevents deposits of dirt and facilitates cleaning.
- Its ergonomic handle provides a perfect grip, even with wet hands.
- Double-walled door with safety microswitch and high quality seal.
- 38 cm loading capacity: high versatility for washing a wide range of items: dishes, Euronorm trays, GN 1/1 tubs and Ø 39 cm pizza plates.
You will never WASH ALONE
- Tech Services: our team of technicians will help you so that your machine is always ready for use.
- Design Services: tell us what your needs are and we will advise you.
- 60 years of experience and know-how at your disposal.
Compact tank volume
Maximum efficiency.
Hydroblade™ washing arms
Water savings, washing efficiency, strength and durability.
"Easy-on" surface filters
Extremely easy assembly and disassembly.
"Easy-grip" door
Design with integrated door handle.
Large capacity
380 mm door clearance.
Double rack option
Add the double rack accessory and double your dishwasher's output.
Comparison
| ACTIVE | ULTRA | |||||
|---|---|---|---|---|---|---|
 | | | | | | |
| AX-50 | UX-50 LITE | UX-50 | UX-50C | UX-50 ISO | UX-50 ISO C | |
| Features | ||||||
| Basket dimensions | 500 x 500 mm | 500 x 500 mm | 500 x 500 mm | 500 x 500 mm | 500 x 500 mm | 500 x 500 mm |
| Useful height | 380 mm | 380 mm | 380 mm | 380 mm | 380 mm | 380 mm |
| Electronic control panel | yes | yes | yes | yes | yes | yes |
| Wash temperature display | - | yes | yes | yes | yes | yes |
| Rinse temperature display | - | yes | yes | yes | yes | yes |
| Constant temperature rinsing | - | - | opt. | yes | opt. | yes |
| Rinse pressure pump | - | - | opt. | yes | opt. | yes |
| Wash tank capacity | 14 l | 14 l | 14 l | 14 l | 14 l | 14 l |
| Double skin | - | - | opt. | opt. | yes | yes |
| Cycles | ||||||
| Cycles | 3 | 6 | 6 | 6 | 6 | 6 |
| Cycle duration | 120 / 150 / 210" | 90 / 110 / 120 / 180 / 240" | 90 / 110 / 120 / 180 / 240" | 90/110/120 / 180 / 240" | 90 / 110 / 120 / 180 / 240" | 90 / 110 / 120 / 180 / 240" |
| Production baskets / hour | 30 / 24 / 17 | 40 / 33 / 30 / 20 / 15 | 40 / 33 / 30 / 20 / 15 | 40 / 33 / 30 / 20 | 40 / 33 / 30 / 20 / 15 | 40 / 33 / 30 / 20 / 15 |
| Loading | ||||||
| Pump power | 0.75 Hp / 500 W | 1 Hp / 750 W | 1 Hp / 750 W | 1 Hp / 750 W | 1 Hp / 750 W | 1 Hp / 750 W |
| Tank | 1800 W | 1800 W | 1800 W | 1800 W | 1800 W | 1800 W |
| Boiler | 2800 W | 3000 W | 5000 W | 5000 W | 5000 W | 5000 W |
| Total loading | 3300 W | 3750 W | 5750 W | 5750 W | 5750 W | 5700 W |
| External dimensions (W x D x H) | ||||||
| External dimensions (W x D x H) | 580 x 640 x 835 mm | 580 x 635 x 835 mm | 580 x 635 x 835 mm | 580 x 635 x 835 mm | 600 x 640 x 835 mm | |
| Please note: the width of double skinned models increases by 20 mm. | ||||||
| Data with water entry at 55ºC (recommended) | ||||||
