Pot washers
Utensil washers
New UX Range of utensil washers with high loading capacity and pressure: ensure optimal washing and hygienic results.
UX-600
Rack size 600 mm x 630 mm and door clearance 650 mm. Constant temperature rinsing system.
Utensil washer UX-600V
Rack size 600 mm x 630 mm and door clearance 650 mm. Constant temperature rinsing system. HRS system.
UX-750
Rack size 780 mm x 700 mm and door clearance 820 mm. Constant temperature rinsing system.
Utensil washer UX-750V
Rack size 780 mm x 700 mm and door clearance 820 mm. Constant temperature rinsing system. HRS system.
UX-1300
Rack size 1320 mm x 700 mm and door clearance 820 mm. Constant temperature rinsing system.
Utensil washer UX-1300V
Rack size 1320 mm x 700 mm and door clearance 820 mm. Constant temperature rinsing system. HRS system.
LU-60
600 x 630 mm basket.
LU-75
780 x 700 mm basket.
LU-61H
630 x 550 mm basket. Maximum loading height: 820 mm.
LU-130
1350 x 700 mm basket.
Ideal to wash big sized pots and wares in restaurants, ice-cream shops, patisseries and butchers, etc.
Maximum quality construction
- Constructed from stainless steel.
- Double skin: silent operation and reduction of thermal dispersions.
Perfect hygienic results
- Powerful, high-pressure apppliances.
- Rounded wash tank avoids dirt accumulation in corners.
- Stamped wash dispersers in stainless steel tubes.
- Easy to remove wash and rinsing dispersers.
- Complete with rinsing boiler and booster pump.
- The standard booster pump ensures effective high-pressure rinsing, regardless of the pressure and flow rate of the mains water supply.
- Self-cleaning cycle.
Efficiency and savings
- Standard “THERMAL LOCK” function to guarantee hygienic effectiveness.
- Standard “ENERGY SAVING” mode.
- Saving on rinse water consumption and tank filling: 35% water savings compared to the previous range.
Maximum comfort and safety for the user
- Double door opening with counterweight: minimal effort.
- Extended loading height.
- Advanced UX control panel. Quick and intuitive temperature reading.
- Fully removable stainless steel basket: facilitates loading and unloading.
- Door equipped with a safety microswitch.
- HRS system available on all models: environmental improvement in the workplace and heat recovery thanks to the steam condenser, available for all models.
Color LCD display: new UX control panel
- Advanced image clarity to facilitate screen reading from any angle and distance.
- Quick and intuitive reading of machine information and status through messages, color codes, and icons.
- Progress bar for a quick view of cycle progress.
- Easily configurable parameters.
You will never wash alone
- All relevant information and documentation of your machine at your fingertips thanks to the QR code.
UX utensil-washers
UX-600
Rack size 600 mm x 630 mm and door clearance 650 mm. Constant temperature rinsing system.
Utensil washer UX-600V
Rack size 600 mm x 630 mm and door clearance 650 mm. Constant temperature rinsing system. HRS system.
UX-750
Rack size 780 mm x 700 mm and door clearance 820 mm. Constant temperature rinsing system.
Utensil washer UX-750V
Rack size 780 mm x 700 mm and door clearance 820 mm. Constant temperature rinsing system. HRS system.
UX-1300
Rack size 1320 mm x 700 mm and door clearance 820 mm. Constant temperature rinsing system.
Utensil washer UX-1300V
Rack size 1320 mm x 700 mm and door clearance 820 mm. Constant temperature rinsing system. HRS system.
High loading capacity
Extended loading height with a perfectly counterbalanced door.
Triple savings
Reduced consumption of water, energy, and chemicals.
Perfect hygiene assurance
Hygiene guaranteed with constant-temperature rinsing using a rinse pump. Booster pump as standard.
High power and pressure
Especially suitable for catering, ice cream shops, bakeries, and butcher shops.
Advanced UX panel
LCD color display with quick and intuitive reading.
HRS system: steam condenser option
Removes steam while recovering heat, saving energy.
Comparison
 |  |  |  |  |  |  | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| UX-600 | UX-750 | UX-1300 | LU-60 | LU-75 | LU-61H | LU-130 | ||||
| Basket dimensions | 600 x 630 mm | 780 x 700 mm | 1320 x 700 mm | 600 x 630 mm | 780 x 700 mm | 630 x 550 mm | 1350 x 700 mm | |||
| Useful height | 650 mm | 820 mm | 820 mm | 650 mm | 650 mm | 820 mm | 680 mm | |||
| Cycles | ||||||||||
| Cycles | 5 | 5 | 5 | 3 | 3 | 3 | 3 | |||
| Cycle duration | 120 / 180 / 240 / 360 / 480" | 120 / 180 / 240 / 360 / 480" | 120 / 180 / 240 / 360 / 480" | |||||||
| Production baskets / hour | 30 / 20 / 15 / 10 / 7 | 30 / 20 / 15 / 10 / 7 | 30 / 20 / 15 / 10 / 7 | |||||||
| Loading | ||||||||||
| Pump | 3 Hp / 2200 W | 3,2 Hp / 2400 W | 3 Hp / 2 x 2200 W | 3 Hp / 2200 W | 3,2 Hp / 2400 W | 4 Hp / 3000 W | 6 Hp / 4400 W | |||
| Tank | 6000 W | 6000 W | 9000 W | 6000 W | 6000 W | 5300 W | 9800 W | |||
| Boiler | 9000 W | 9000 W | 12000 W | 9000 W | 10500 W | 8300 W | 19600 W | |||
| Total loading | 11200 W | 11400 W | 16400 W | 11200 W | 12900 W | 11200 W | 24000 W | |||
| External dimensions (W x D x H) | ||||||||||
| External dimensions (W x D x H) | 742 x 852 x 1843 mm | 922 x 932 x 2015 mm | 1465 x 930 x 2015 mm | 742 x 852 x 1840 mm | 922 x 932 x 1840 mm | 675 x 803 x 2015 mm | 1520 x 890 x 1760 mm | |||
| Depth (open) | 1232 mm | 1400 mm | 1374 mm | 1232 mm | 1312 mm | 1150 mm | 1235 mm | |||
| Height (open) | 2035 mm | 2300 mm | 2330 mm | 2035 mm | 2035 mm | 2200 mm | 2080 mm | |||
| Net weight | 168 kg | 216 kg | 322 kg | 168 kg | 196 kg | 150 kg | 220 kg | |||
| Data with water entry at 55ºC (recommended) | ||||||||||
