Blast chillers / freezers

Blast chilling, shock freezing and automatic preservation

Sammic blast chillers are designed to improve the quality and organisation of the work in restaurants, confectioneries, bakeries and ice-cream shops. Great power, versatility and reliability are the most evident features of Sammic blast freezers. Sammic blast chillers / freezers improve the work of operators, leaving more time for creativity.

10 models

AT-3 2/3

3 x GN 2/3 (distance between trays: 70 mm).

AT-3 1/1

3 x GN 1/1 (distance between trays: 70 mm).

AT-5 1/1

5 x GN 1/1 / EN 600 x 400 (distance between trays: 70 mm).

AT-8 1/1

8 x GN 1/1 / EN 600 x 400 (distance between trays: 70 mm).

AT-10 1/1

10 x GN 1/1 / EN 600 x 400 (distance between trays: 70 mm).

AT-14 1/1

14 x GN 1/1 / EN 600 x 400 (distance between trays: 65 mm).

AT-12 2/70

12 x GN 2/1 (distance between trays: 70 mm).

AT-20

1 trolley(s) GN 1/1 / 1 trolley GN 2/1 / EN 600 x 400 / EN 600 x 800. Built-in motor.

AT-20 (COMPATIBLE)

1 carriage 20 x GN 1/1 compatible with ovens. Built-in motor.

AT-20 MD

1 trolley GN 1/1 / 1 trolley GN 2/1 / EN 600 x 400 / EN 600 x 800. Remote motor.

Quick chilling helps to maintain the quality of food, preserving the nutrients and improving the efficiency of cooking processes.

A wide range of applications

Frozen pizzas, fresh pasta, confectionery, gastronomy, ice creams, desserts, baked goods, etc.

One piece of equipment, several functions

Quick chilling to +3ºC, which inhibits bacterial proliferation, prevents food dehydration due to evaporation and makes it possible to preserve the original properties of food for five to seven days.
Deep-freezing to a core temperature of -18ºC in less than four hours, avoiding the formation of macrocrystals, an essential requisite if - at the time of use - unfrozen food is to keep its original consistency and quality.
Automatic preservation at the maintenance temperature programmed after each operation.

Robust, hygienic and reliable construction

Manufactured in stainless steel with hygienic cathodic protection and easy to clean.
Insulation with expanded polyurethane foam in water free of CFC's and HFC's.
High-power compressors for quick chilling.
Indirect air flow.
Freon refrigerant with a low GWP content.
Evaporators treated with cataphoresis to reduce odours and moulds, favouring performance and durability over time.

Advanced control panel

Cycles per temperature, time or core probe.
HARD function for rapid cooling, SOFT for deep-freezing.
Data storage at the end of the cycle.
Possibility of customising and saving cycles and settings.
HACCP functions for storing alarms.
Bluetooth connectivity for maximum control over processes.

Special cycles

Pre-cooling.
Sanitation of raw fish.
Ice cream hardening.
Other optional cycles: defrosting, internal sterilisation, cooling by core probe.

Comparison


	AT-3 2/3	AT-3 1/1	AT-5 1/1	AT-8 1/1	AT-10 1/1	AT-14 1/1	AT-12 2/70	AT-20	AT-20 (COMPATIBLE)	AT-20 MD
Features
Recipient capacity (GN) 2/3	3
Recipient capacity (GN) 1/1		3	5	8	10	14
Recipient capacity (GN) 2/1							12
Space between trays	70 mm	70 mm	70 mm	70 mm	70 mm	65 mm	70 mm
Trolley (gn) 1/1								1	1	1
Trolley (gn) 2/1								1		1
600 x 400 trolley								1		1
600 x 800 trolley								1		1
Core probe	yes	yes	yes	yes	yes	yes	yes	yes	yes	yes
Chilling capacity
Chilling capacity in	90'	90'	90'	90'	90'	90'	90'	90'	90'	90'
Chilling capacity - performance	7 kg	7 kg	20 kg	25 kg	28 kg	39 kg	70 kg	90 kg	75 kg	90 kg
Deep freeze capacity - in	240'	240'	240'	240'	240'	240'	240'	240'	240'	240'
Deep freeze capacity - performance	4.9 kg	5 kg	14 kg	16 kg	18 kg	23 kg	40 kg	65 kg	45 kg	65 kg
Consumption	700 W	720 W	1000 W	1400 W	3600 W	3800 W	3800 W	3900 W	3800 W	4500 W
External dimensions (W x D x H)
Width	600 mm	600 mm	820 mm	820 mm	820 mm	820 mm	820 mm	890 mm	945 mm	1000 mm
Depth	605 mm	864 mm	740 mm	700 mm	800 mm	800 mm	1130 mm	1397 mm	1116 mm	1055 mm
Height	400 mm	460 mm	900 mm	1280 mm	1750 mm	1750 mm	1825 mm	2450 mm	2445 mm	2220 mm
Net weight	42 kg	55 kg	90 kg	140 kg	190 kg	190 kg	250 kg	450 kg	360 kg	455 kg
